CONCRETE TOOLS & EQUIPMENT

20" WALK BEHIND CUT SAW ELECTRIC 230/480


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Daily: Call For Quote

Quantity:

Info

20" ELECTRIC WALK BEHIND CUT SAW
CAN FIT 14"-20" BLADES
20 INCH BLADE (7-5/8" MAX SAW CUT) 230 VOLT OR 480 VOLT 3 PHASE ELECTRIC CUT SAW.
COMES WITH A MALE L16-30 (480 VOLT) PLUG END WITH A 2-3' PIGTAIL CORD ON UNIT
REQUIRES 20KW MINIMUM GENERATOR TO OPERATE
FOR A CORD END, USE MALE/FEMALE L1630C & L1630P P/N'S
ALSO USE MINIMUM SIZE, 6-4 SOO CORD.
WHEN USING 6/4 SO CORD CAN USE UP TO 350' CORD
WHEN USING 8/4 SO CORD CAN GO UP TO 300' MAX!
WHEN USING 10/4 SO CORD CAN GO UP TO 200' MAX!
FLA (FULL LOAD AMPS) AKA-RUNNING AMPS AT 230VAC-24AMPS 480VAC-12 AMPS
STARTING AMPS 230VAC-120AMPS 480VAC-60 AMPS
14" BLADE CUTS UP TO 4-5/8" MAX DEPTH
18" BLADE CUTS UP TO 6-5/8" MAX DEPTH
20" BLADE CUTS UP TO 7-5/8" MAX DEPTH.
Push or self propelled drive, Screw feed (CRANK UP/DOWN) raise and lower,Left or right side sawing,lifting hook for convenient lifting solutions.
